product brief

ef2 series fpga products are the second generation of the “elf” series launched by anlogic infotech,

involving soc fpga products with embedded mcus. the products are based on 55 nm low-power technology and feature versatile configurations, high performance, and rich internal resources.

they are positioned in fields such as video capture, industrial control, and communications with far ranging adaptability.

contact sales

product table

find 9 results

dffs	luts	distributeram	eram-9k	eram-32k	eram-128k	eram-256k	eram-totalbrambits	m18*18	pll	adc	user io	package methods	package size
1500	1500	12k	6	3	1	1	546k	8	1	2	81	lqfp100	14*14
1500	1500	12k	6	3	1	1	546k	8	1	2	114	lqfp144	20*20
1500	1500	12k	6	3	1	1	546k	8	1	2	207	fbga256	17*17
2500	2500	20k	9	4	1	1	607k	12	1	2	29	xwfn42	4.2*4.2
2500	2500	20k	9	4	1	1	607k	12	1	2	207	fbga256	17*17
4480	4480	35k	12	6	1	1	700k	15	1	2	114	lqfp144	20*20
4480	4480	35k	12	6	1	1	700k	15	1	2	207	fbga256	17*17
4480	4480	35k	12	6	1	1	700k	15	1	2	36	lqfp48	9*9
4480	4480	35k	12	6	1	1	700k	15	1	2	57	bga81	4.2*4.2

product features
application scenarios
materials download

product features

flexible logical structure

logic scales from 1500 to 4480 luts
built-in flash

support fast power-up, no external device required
high performance io

support hot-swapping and mipi hs/lp io optimization
enhanced security design

each chip has a unique 64-bit dna with aes encryption support for the bit stream
